Utilitarian Flush Storage Tube
Created 3 months ago
Description
This monolithic flush-fit cylinder is built to securely house a 38x110mm object. Designed with a seamless exterior, the cap integrates a deeply cut coarse thread that bites firmly and closes flush with the main body walls. The top features a dedicated multi-part text inlay, arranged in an arc, ready for a multi-material print or a precise press-fit assembly.
Design Details
- Clearances: 40.5mm internal diameter with a 112mm depth ensures no binding.
- Mechanism: Coarse 4mm pitch threads with 0.8mm diametrical clearance.
- Grip: 12 vertical flutes cut into the cap for torque.
- Inlay: Text elements are separated into their own part for dual-color extrusion.
Photos
Technical views
