200 mm Pen with Compact RC Mount
Created today
Description
A 200 mm display pen with an 11 mm round barrel, a tapered tip, a pocket clip and "HECTEC SONDEREN" engraved on the front. A small base plate with two cradles sits under the barrel near the tip end, for mounting the pen on an RC car.
The pen is held in the cradles with zip ties, and the plate is fixed down with one central screw.
- Pen length: 200 mm, barrel diameter 11 mm
- Mount plate: 46 x 24 mm, located at the tip end of the barrel
- Two cradles with zip-tie slots beside each
- One 3.6 mm screw hole in the plate centre
- Solid barrel, display use only
