5-Tier SNES Cartridge Display
Created today
Description
A stepped, five-tier display stand designed to hold retro game cartridges upright. The staggered arrangement fans out the cartridges to keep front labels visible without stacking, providing a structured alternative to bulk box storage.
- Capacity: Five slots configured in a stepped vertical arrangement.
- Fitment: 20.5mm slot width accommodates standard SNES cartridges with operational clearance.
- Orientation: 10-degree rearward lean maximizes label readability.
- Structure: Relieved underside bridge minimizes material usage while maintaining base stability.
Images
