90mm Meshing Token Tray

Made by MagnetCapybara

Created 3 months ago

Storage & Organizationboard-gametoken-trayhexagonalstackingmodularribbeddice-tray
Remix this model →

Description

A modular hexagonal tray and lid set for organizing board game tokens and dice on the table. The trays measure roughly 78mm flat-to-flat and 90mm point-to-point.

Fitment details

  • Mating surfaces: Vertical interlocking uses a standard 3mm stacking boss with 0.5mm radial clearance to ensure parts don't fuse or stick.
  • Side meshing: The exterior tray walls feature vertical ribbing spaced at 4mm to interlock with neighbouring trays, keeping clusters tight.
  • Inner dimensions: The interior floor features a deep 6mm slope so chits and small tokens will slide cleanly into your hand instead of trapping in the sharp hexagonal corners.
  • Clearances: The lid shares the stacking boss but drops the outer ribbing for easier grip and clearance.
