Advent Calendar With 24 Drawers
Created today
Description
Advent calendar drawers that stick, fuse, or have nothing to grab. Each of the 24 drawers has a rounded finger grip on the front, a numbered face, and 0.5 mm clearance all round, so it slides out freely after printing in place.
Key numbers
- Footprint: 177.5 × 157.5 mm (fits a 180 × 180 mm bed)
- Height: about 49.9 mm including grips
- Layout: 4 columns × 6 rows, printed lying on its back, front facing up
- Drawer interior: 38.5 × 22 × 42.5 mm
- Walls: 1.5 mm; grips 8 × 5 mm, 2.5 mm proud
- Print: white PLA, 0.4 mm nozzle, no supports inside the drawers; the drawer back walls hover 0.4 mm above the frame back, so expect a thin first-layer bridge
