Archiv-Einschub: Schiffe versenken

Made by SaffronMinnow

Created 1 months ago

Storage & Organizationbrettspiel-organizerschublademodulartext-inlaypress-fitprint-in-place-huellaufbewahrung
Remix this model →

Remixed once

Description

Ein maßgefertigtes, modulares Schubladen-Regal für Brettspiele und Kartensets (hier ausgelegt auf 150 x 45 mm Boxen).

Das Set besteht aus drei Teilen:

  • Regalgehäuse: Eine stapelbare, robuste Außenhülle mit Fase.
  • Schublade: Passgenau mit 0,8 mm Spielraum zum einfachen Herausziehen. Ein Griff an der Front erleichtert das Greifen.
  • Inlay-Buchstaben: Die Schrift ist als 1,5 mm tiefe Aussparung in der Frontplatte angelegt. Die separat gedruckten Buchstaben sind minimal verkleinert (0,15 mm Toleranz) und können nach dem Druck passgenau in die Front eingedrückt werden.

Ideal für ein aufgeräumtes Regal, bei dem man jedes Spiel sofort auf der Frontblende erkennt.
