Made by GantryTerrapin
Created 1 months ago
Description
A sturdy tray that hangs over a bunk bed rail, keeping bedtime essentials close at hand.
Images

What it's for A four-compartment cutlery separator tray for a drawer, with semi-round finger cutouts in each divider so utensils lift out easily. Dimensions Overall height: 30 mm, with a 3 mm base and 3 mm walls Three compartments 240 mm long: 50, 60 and 65 mm wide One 55 mm wide, 185 mm long compartment beside the 65 mm one Finger cutouts: 24 mm diameter semicircles centred on each divider Remix ideas Change the cutout radius for deeper or shallower scoops Split the tray into pieces for smaller print beds Add a lip or feet for drawer grip
A minimalist two-piece sliding storage drawer: a ribbed outer housing with an open front and a separate inner drawer with a flush, handle-free face. The housing measures 100 × 150 × 60 mm with 10 mm rounded outer corners and 1.6 mm walls. Vertical ribbing stiffens the side walls, and thin 45° guide rails keep the drawer aligned. The guide rails and side stop tabs stay inside the outer walls, with only the ribs standing proud by design; the front ends of the rails stop inside the rounded front corners. The top is an open frame with a 12 mm solid rim, thickened to 3.4 mm so the stacking recess does not cut through. The drawer slides on the rails and locks closed with rounded snap bumps that seat into grooves in the housing. Push the drawer inward to release the bumps; the rear U-shaped leaf spring then pushes it forward. The spring is 0.95 mm thick and 40 mm wide, anchored to the inner back wall and touching the floor only where it meets that wall. A 45° chamfer under its bottom edge lifts the loop clear of the floor as it runs forward, so it flexes freely and still prints without supports — the trade-off is a shorter front loop, so the spring is on the soft side. A 45° finger bevel under the bottom front edge gives a hidden pull once the drawer has popped out. Flexible side stop tabs catch pockets near the back of the drawer, limiting travel to about 95 mm; press the tabs aside to remove the drawer fully. The stop pockets are 1.2 mm deep with 1.4 mm of solid wall behind them. The housing also stacks: a 1.5 mm bottom foot, inset 2.2 mm with a 45° chamfer, sits in a matching 1.8 mm recessed step on the top rim with 0.3 mm clearance. Housing: 100 × 150 × 60 mm, ribbed sides, open top with 12 mm rim, 10 mm rounded corners, 1.6 mm walls Drawer: 95.7 × 135 × 53.2 mm, flush front, no handle, side snap bumps Release: push-push detent with rear U-spring Pull: hidden 45° finger bevel under the front bottom edge Stop: flexible side tabs limit travel to about 95 mm; press aside for full removal Stacking: 1.5 mm bottom foot and matching 1.8 mm top recess Printing: two separate pieces, no supports, overhangs 45° or shallower Tuning: spring force and detent interference may need adjustment after a test print

Open-top storage box with three equal compartments side by side, and the name CHARO raised across the full front face. Outer size: 210 x 112 x 85 mm Walls and dividers: 3 mm Floor: 4 mm Compartments: 3, each about 66 x 106 mm inside Lettering: Bebas Neue, about 200 x 77 mm, raised 1 mm on the front Prints upright with no supports
What it's for A plain open-topped square box with a closed floor, sized to hold small parts, tools, or loose odds and ends on a desk or workbench. The straight sides and flat base keep it stable on the print plate and easy to drop things into from above. Dimensions Outer footprint: 75 × 75 mm Height: 25 mm Wall thickness: 3 mm Floor thickness: 3 mm Top: fully open, no lid Print notes Prints upright as it sits, with no supports needed for the vertical walls. A 3 mm wall and floor hold up well in PLA or PETG at a standard layer height; thicker walls take a slightly wider nozzle or more perimeters comfortably. Remix ideas Add a lid or a stacking lip so several boxes can sit on top of one another. Round the outer corners for a softer look and less sharp handling. Divide the interior with a grid to sort small hardware.
PivotTee è un portabrugole piatto per chiavi a T da 10 a 3 mm, con perni laterali che lo fanno ruotare da orizzontale a verticale su una base da fissare al cassetto. Un fermo girevole dietro il blocco lo tiene in verticale durante l'uso, e il perno centrale accoglie un inserto filettato M3 per avvitare il fermo. Caratteristiche Otto sedi da 10 a 3 mm con fessura superiore e numeri incisi Base con due fori svasati da 5 mm Perno del fermo da 8 mm con foro da 4,2 mm per inserto M3 (profondità circa 8 mm) Fermo girevole 44 × 14 × 6 mm Print notes Tre pezzi stampati sdraiati, senza supporti Inserto filettato da scaldare a caldo nel foro del perno
Spiral shoe rack with six 60° steps around a central column on a round base, one pair of shoes per step. Each step has a dovetail tongue that slides down into a matching slot in the column, so steps can be removed or attached individually. Steps: 18 mm flat plates, 4 mm outer lip, 90 mm rise per step Overall size: 600 mm diameter, 540 mm tall Base: 300 mm diameter, 12 mm thick, chamfered Clip: dovetail 15 mm deep, 0.3 mm slot clearance Removal: lift the step straight up Print steps flat; column upright; large size may need scaling or sectioning
