Doll Wardrobe With Opening Doors
Created today
Description
Doll wardrobe whose doors stay shut and never swing, because they are glued-on slabs. This one has two doors on pin hinges that actually open, with a centre divider and a hanging rail inside.
Key numbers
- Overall size: 200 mm long x 50 mm deep x 200 mm high
- Walls and shelves: 6 mm; back panel 4 mm
- Doors: 4 mm thick, sit flush in the front opening with 0.6 mm clearance
- Hinge pins: 3 mm, in 3.8 mm sockets in the top and bottom panels
- Hanging rail: 5 mm round bar, 30 mm below the top
Printing
- Print the body upright, open front facing you.
- Print the doors standing on their long edge, pins pointing up and down; pin ends need no supports.
- Drop each door's lower pin into its socket first, then tilt the top pin in.
- Rail and knobs are separate pieces to print and glue in place.
Photos
Technical views
More like this
Explore more in Decor & Display →
Barbie Wardrobe With Hinged Doors
