Expanded Metric Thread Gauge
Created today
Description
A benchtop reference block for identifying standard metric coarse threads. Contains female threads from M3 to M14.
Specifications
- Range: M3, M4, M5, M6, M8, M10, M12, M14
- Style: Internal threads for checking bolts
- Tolerances: Threads are modeled with internal clearance to account for typical FDM printing expansion, allowing bolts to thread smoothly without post-processing tap runs.
