Fabrication-Ready Welded Railing explode
Created today
Description
A heavy-duty 2-meter railing section designed for real metal fabrication. The components are drafted with realistic 2mm root gaps at every joint and heavy 4mm chamfers simulating weld bevels, so the model accurately reflects standard weld-prep fitment.
- Overall Size: 2000mm long by 1500mm tall.
- Post Size: 60mm square stock.
- Rails: 50x40mm profile, with a 120mm bottom clearance.
- Balusters: 20mm square, 150mm on-center spacing.
- Joinery: Ends are shortened by 2mm and heavily chamfered to provide a realistic V-groove root gap for welding.
