Four — Supported Desk Weight

Created 3 months ago

Decor & Displaynumber-4stencil-fontdesk-weightdisplayno-supportsprint-in-place
Remix this model →

Description

A solid, stylized number "4" with a built-in backing plate. The original stencil font separates the number into multiple islands, so this 2mm base ensures the entire character prints as a single connected object.

Features

  • Stencil Font: Uses a bold, military-style stencil look.
  • Unified Base: A 2mm thick rounded backplate bridges the gaps.
  • Print Ready: Sits flat on the build plate with no supports required.
