Hilti Nuron Battery Mount
Created 5 days ago
Remixed once
Description
A wall-mounted receiver bracket for Hilti Nuron batteries.
Heavy battery packs love to lever short brackets right out of the drywall. This bracket gives them a solid vertical footprint to spread that load, catching the battery's sliding interface on an internal U-channel with a dead stop at the base.
- Internal Channel: 63mm wide (48mm opening)
- Clearance: Counter-sunk screw holes keep the hardware below the sliding surface
- Detail: Features a debossed HILTI logo on the backplate that stays clear of the sliding path
Photos
Technical views
