Kawasaki M12x1.25 Skirted Mirror Cap
Created 1 months ago
Description
Threaded blanking cap for M12x1.25 motorcycle mirror mounts, designed to seal the exposed mounting boss after switching to bar-end mirrors. The flat, beveled head deflects weather, while the outer lip drops down over the factory hardware to stop water getting underneath.
Fitment and Specifications
- Thread Standard: M12x1.25 fine pitch.
- Critical Check: Verify the factory bore diameter on the motorcycle. While this model is cut for M12, a significant number of Kawasaki factory mounts use M10 threads.
- Clearance: The 3mm deep weather skirt has an 18.5mm internal diameter, providing 0.25mm of radial clearance over a standard 18mm factory boss.
- Known Incompatibilities: Yamaha and certain right-hand Kawasaki mounts use a reverse (left-hand) thread. If the printed cap refuses to thread into the right side, mirror the geometry in the slicer or remix to reverse the thread direction.
Images
More like this
Explore more in Automotive, RC & Hobby →
Double Seatbelt Buckle Holder, Backseat
Two seatbelt buckles flop around and fall into the seat gap, so this holder stands both upright side by side in the backseat of a Toyota Sienta. Each 33 x 53 mm pocket goes straight through the base, so the buckle and webbing pass through with nothing blocking the bottom. Pocket size: 33 x 53 mm each, sized for a 31 x 51 mm buckle Sleeve height: 28 mm above a 6 mm base Overall footprint: 130 x 64 mm Centre screw hole: 4.5 mm Print flat on the base, no supports needed
Line Follower Chassis (N20/Mega)
A flat-printing, modular chassis designed specifically for high-speed line following. Engineered to accommodate an Arduino Mega 2560, dual N20 motors, and a Pololu QTR-8RC reflectance sensor, with priority placed on a low center of gravity and straightforward field maintenance. What it's for This frame carries the electronics and drive system for a 2WD differential steering robot. Components drop into dedicated regions rather than requiring complex brackets, and all sensitive electronics are kept clear of the track surface. The front sensor mount separates from the main plate to allow independent height tuning of the IR array. Dimensions Overall envelope (assembled): 180 mm (L) × 130 mm (W) × 55 mm (H) Track width: ~90 mm, providing clearance for 35–38 mm diameter wheels. Electronics rails: Slotted cross-members accept an Arduino Mega or similarly sized microcontrollers. Drive mounts: Drop-in snap/strap cradles for standard 12×10 mm N20 motors. Power bay: Sized for two parallel 18650 lithium cells (44 mm inner width) with integrated Velcro pass-throughs. Assembly All major features anchor with standard M2 or M3 hardware. The front skid and sensor bracket print flat independently and bolt into designated sliding rails on the chassis nose. The motor mounts include under-plate zip-tie channels to secure the gearboxes rigidly against torque. Use standoffs for the motor driver and buck converter pads to ensure proper wiring clearance above the deck.
Freelance Lego fitting cab with Headlight Studs
