Mandarin Community Town Model
Created today
Remixed once
Description
What it's for
A small-town community model for a Mandarin class project. Each facility carries a Chinese, pinyin and English label, and the action words appear on signs, a banner and people scenes.
Dimensions
- Base: 200 × 200 mm, 4 mm thick
- Buildings: 46 × 28 mm, 32 mm tall
- Labelled places: 医院, 图书馆, 社区中心, 商店, 学校, 公园
- Action words: 工作 and 服务 on signs, 一起参加活动 on the park banner, with people grouped together
- Extras: road, paths, trees, houses, cars, benches, streetlights, neighbours
Remix ideas
- Add more houses with 邻居 labels
- Swap the school for another facility
- Print in several colours to paint or assemble per group
Images
More like this
Explore more in Decor & Display →
Mandarin Community Town Model
A tabletop town for practising Mandarin place words, where flat labels get lost. Each building, sign and park area carries its Chinese characters, pinyin and English on the front face, so the vocabulary sits right on the thing it names. Details that matter Base: 200 × 200 mm, 4 mm thick plate Buildings: hospital, library, community center, store and school, each 46 × 28 mm footprint Extras: park with pond, road, footpaths, houses, cars, trees, lamps and figures Colour regions: ground, road, walls, roofs, doors, lettering, signs, trees, lawn, pond, paths Print: large bed needed (or scale down); multicolour or paint by region; lettering is 0.8 mm raised, so use a 0.4 mm nozzle
Mandarin Town — Colorful Community Scene
A bright miniature town for learning Mandarin community vocabulary. Each building carries its name in Chinese, pinyin and English, and every main building has its own wall colour. Signs, a park, a pond, houses, cars and people fill out the scene. Features Hospital, library, community center, store and school, each in a different colour Park with pond, benches and trees, plus a banner reading 一起参加活动 Road with cars, footpaths, lamps and neighbourhood houses Work and Service signs with people at the buildings Dimensions 200 × 200 mm base plate, 4 mm thick
Electronics Box With Solar Panel
A wildlife alert electronics box with a tilted solar panel on top, and no post or base to tip over. The box sits flat on the table, and its two front holes stay stacked on one centre line. Box: 110 × 70 × 60 mm, 3 mm walls, lid held by four screws Front holes: 5.2 mm amber LED above a 24 mm PIR sensor opening Solar panel: 110 × 100 mm at 30°, on two printed brackets Printing: FDM, no supports needed for the lid; print the box with its open back facing up
Anel de Guardanapo com Cruz
Anel de guardanapo com cruz à frente, para o tecido não escorregar nem ficar solto na mesa. A cruz fica separada do círculo e presa por uma ponte sólida, em uma peça única. Diâmetro interno do anel: 45 mm, parede de 3 mm, altura de 5 mm Cruz: 50 mm de altura, haste de 12 mm de largura e 5 mm de espessura Ponte de ligação: 8 mm de largura, 12 mm de altura Impressão FDM em PLA; a parte de baixo do anel elevado pode pedir suporte
Lamp Bases, Shades and Diffuser Set
A set of mid-century lamp parts that all share one coarse 6 mm-pitch thread, so any shade fits any base. The set has two fluted shades (round and square ribs), a white adjustable diffuser and several bases: tall, short, grooved, two tripods, a flat-leg grooved tripod and a dowel-leg hub. Remix hooks Flat-leg tripod: legs are 16 mm wide slabs (before scaling) with two grooves, 3.2 mm wide, down each outer face. Change the groove count, offset (±4 mm) or width. Leg height and spread: hub height 70 mm and foot radius 70 mm set the splay. Raise both for a taller version. Thread spigot: 52 mm across, 38 mm long. Keep it to stay compatible with the shades. Pairs with: either fluted shade and the diffuser. The 42 mm bore runs straight through for the bulb and cord.
Teardrop Lamp Parts, Terracotta and Wood
A mid-century teardrop table lamp laid out as separate print pieces: fluted base, threaded crown collar, hollow prolate-spheroid diffuser and three dovetail-cleat prongs. A second set of the base, crown and prongs is included in a walnut-style wood tone, so one diffuser works with either finish. Remix hooks Wood finish: the wood set is the same geometry in a different colour. Print it in wood-fill or walnut-toned filament, then sand and oil it. Real grain would need a textured surface, which is a good next step. Fit: the thread clearance is about 0.4 mm and the cleat clearance about 0.3 mm. Adjust these to suit your printer. Bulb: it is sized for a 127 mm T10 or an ST19. The crown bore is 31 mm and the diffuser opening is 36.5 mm. Pairs with: an E26 socket, plus a small glue dab or set screw if you want the cleats locked. The tallest piece, a prong, is about 203 mm, so everything fits a 256 mm bed.
