Modular Rack Mount System
Created today
Description
A modular organizing system designed to bridge a 19-inch rack using standard M8 threaded rods. Drop-in slices let you swap and position devices without taking the rails apart.
- Upright Slots: Vertical compartments tailored for MacBooks, Mac Minis, and standard routers.
- Showcase Shelves: Tilted, open-front bays with a retaining ridge and central cable channel for displaying small hubs like a Raspberry Pi, Hue Bridge, or Homey.
- Drop-In Fit: Each module features open-bottom slots, dropping securely over the support rods without requiring complete disassembly.
