Offset Cart Spacer Hook

Made by NozzleLaser

Created 3 months ago

Storage & Organizationcart-hookheavy-dutypetgspacersupport-bracefunctional
Remix this model →

Description

A heavy-duty mounting hook designed to jump over a cart's top lip and drop down flush against the main side wall. This model includes a spacer brace that sits dead-center behind the hook's lower curve, squaring the load firmly against the side of the cart so it stays plumb under heavy weight. The entire bottom corner is filled solid to prevent flexing at the joint.

Remix Dimensions

  • Top Clearance: 22.5mm width for the top cart edge.
  • Lip Jump: Steps out 20mm to clear the side lip.
  • Spacer Clearance: Drops exactly 40mm before the spacer starts pushing back against the cart.
  • Thickness: 12mm thick continuous walls printed flat for extreme layer-adhesion strength.
  • Hook Loop: 40mm inner diameter open-top hook.
