Phone Stand with Cable Channel

A phone stand that holds the phone upright in portrait or landscape, with a cable channel so the charger doesn't pin the phone down or dangle off the edge. Most stands either tip the phone back too far to tap or force the cable to loop around the outside. This one leans the phone at 70° from horizontal and routes the cable up through the stand to the back of the phone.

What decides fit and print

• Lean angle: 70° from horizontal, steep enough to tap the screen and upright enough to watch video.
• Groove: runs the full 90 mm width, so the phone sits in it in either orientation. It is sized for a phone in a thin case.
• Cable channel: 12 mm wide, open on the underside of the base. It runs in from the back, then rises through a 12 x 12 mm opening in the groove floor.
• Overall size: 90 mm wide, about 56 mm deep and 70 mm tall.
• Printing: the flat base goes down on the bed. The underside channel is a 7 mm-tall tunnel, so print it with bridging on or light supports. No other supports are needed.
• Material: PLA or PETG both work. Use 3 or more perimeters for a stiffer groove lip.
