PurrFeed — Cat Food Dispenser
Created today
Description
Meet PurrFeed — a clean, wall-mounted gravity dispenser designed specifically for 3oz (85g) cat food pate tins, such as Kirkland Signature or Fancy Feast. Load the cans in from the top, and pull them out one by one from the bottom chute.
The vertical design takes up zero counter space, and a front viewing channel lets you see exactly how many portions are left before it's time to restock.
Features
- Gravity Feed System: Holds roughly 6 cans at a time; grab the bottom one and the stack cleanly drops down.
- Tactile Retention Bump: A tiny raised lip at the floor of the extraction window keeps the bottom can securely seated until you lift and pull it out.
- Recessed Mounting: Three countersunk wall-mounting holes are located down the spine. The screw heads recess fully into the plastic so they won't scratch the cans as they slide past.
- Sight Window: The 26mm wide front channel gives you a clear view of your supply and doubles as a thumb slot for sliding cans out.
Dimensions
- Overall Footprint: 76mm wide × 76mm deep × 250mm tall.
- Internal Track: 70mm internal diameter (fits standard 65–66mm pate tins with enough clearance to prevent binding).
- Extraction Chute: 68mm wide × 42mm tall.
