QuadraBlock — Mounting Plate
Created today
Description
Meet the QuadraBlock. A heavy-duty 16mm thick mounting plate designed to handle robust anchoring. It features four recessed corner screw holes for flush mounting, alongside deep counterbored center bolt channels for heavy-duty structural attachments. A one-millimeter chamfer wraps the outer edge to prevent sharp corners and improve durability.
Dimensions
- Overall: 92mm x 92mm square, 16mm thick
- Corner Mounting: 4mm through-holes with 8mm diameter recesses (3.5mm deep)
- Center Mounting: 9.5mm through-holes with 18mm diameter recesses (10mm deep)
Features
- Flush Seating: Precision recesses ensure all hardware sits below the top surface.
- Reinforced Core: 16mm thickness provides high rigidity for torque-heavy bolt connections.
- Clean Geometry: Chamfered exterior edges resist chipping and catch less dust.
