Description
A heavy-duty side tray designed to hook right over a bunk bed rail. The interior basin is dimensioned to securely hold a 3.9-inch square box, wrapped by a full 1-inch retaining lip so nothing gets knocked over in the dark.
Dimensions
- Inner Basin: 100 mm × 100 mm (perfect clearance for a 3.9" box).
- Lip Height: 1 inch (25.4 mm).
- Rail Hook: Fits standard 1-inch bed rails.
Print notes
With its 5 mm solid walls, this tray acts as a structural bracket. Best printed in PETG or ABS for long-term creep resistance, though PLA will do fine if it won't see direct sunlight. Depending on your orientation, supports are required for the hook overhang.
