Description
A heavy-duty base piece that sits flat without catching on surfaces. The bottom edge is heavily radiused to clear corners and prevent scratching, while the top houses a precise pocket for mounting.
- Footprint: 65mm diameter x 12mm height
- Top Pocket: 19mm wide, 5mm deep
- Bottom Edge: 5mm radius rounding
