Description
A plate-mounted spool holder for filament spools with large central holes. A hollow 48 mm spindle rises from a flat mounting plate and ends in a flared lip that keeps the spool from sliding off.
Prints plate-down with the spindle pointing up. Mount with the plate against a vertical panel so the spindle points sideways; a pair stacks well for dual spools.
