T-Grip Square Spacers
Created today
Description
A straightforward set of square alignment spacers built to be stacked or swapped easily. Instead of dropping flush where you can't reach them, each spacer features a T-shaped grip tab extending out the front.
- Base: 20.3mm × 20.3mm
- Heights: 5mm, 10mm, 20mm, and 50mm
- Grip: Smooth, fully-rounded T-profile that sits centered on the edge
The grip is 4.5mm thick across the board, offset just enough on the thinnest 5mm spacer to clear the plate. If you need a bolt hole cored through the center or a slot to make them slide-on U-shims, those are easy cuts to add.
