Twin-Chamber Skull Death Whistle

Created today

Gifts, Seasonal & Personalizedwhistleskulldeath-whistlehalloweenaztecnoise-makertwo-chamber
Remix this model →

Description

A skull-shaped death whistle with two resonant chambers for a rough, beating scream. Blow into the mouthpiece at the back; air runs along a flat duct, splits on a sharp edge over the window, and sounds both chambers.

Remix hooks

  • Duct height (2.4 mm): the main pitch and breathiness control. Try 2.0–3.0 mm.
  • Chamber diameters (20 mm and 12 mm): the gap between them sets how harsh the scream is. Closer sizes give a beat, wider gaps a growl.
  • Chamber height (13 mm): taller means lower pitch.
  • Skull shape: cranium radius is 27 mm, jaw block 34 × 40 × 14 mm. Eye sockets, nose and teeth grooves are separate cuts and easy to restyle.
  • Pairs with: a cord through a drilled lug, or a third chamber behind the first.

Overall size is roughly 54 × 78 × 49 mm including the 16 mm mouthpiece. Print upright; the window opens through the crown.
