باکس برد الکترونیکی سفارشی
Created 9 days ago
Description
این باکس محافظ برای یک برد الکترونیکی با ابعاد ۱۰۰ در ۲۸ میلیمتر طراحی شده است.
ویژگیهای باکس
- لبه داخلی: یک لبه در عمق ۲ میلیمتری برای نشستن دقیق برد.
- پورتها: دارای جایگاه اختصاصی برای پورت USB-C و پورت شبکه با ارتفاع ۱۶ میلیمتر.
- رابط کاربری: روی سقف یک بریدگی ۲۶ در ۱۰ میلیمتری برای نمایشگر OLED و سه سوراخ برای دکمهها قرار دارد.
Images
More like this
Explore more in Workshop & Tools →
Biofloc Monitor Station Enclosure
An enclosure is only as good as the snarl of wires it prevents. This is a heavy-duty two-part monitor housing built specifically for FDM printing, designed to group, separate, and anchor a complete suite of biofloc water-quality electronics without turning into a bird's nest inside. The layout isolates the battery compartment at the bottom and keeps the DC buck converters and relay in a ventilated top section, leaving the central deck clear for the ESP32 and an array of sensor interfaces. Internal divider walls double as cable routing channels, forcing the wiring to stay orderly. Core Features Printability: Both halves print completely flat on the build plate (Z=0). The integrated bottom handle is flush with the front face to avoid overhangs. Dimensions: 170 mm width × 250 mm height × 75 mm depth. Hardware Required: 6× M3 screws for the rear cover; additional M3 hardware for the internal standoffs and the 16x2 LCD faceplate mount. Ports: Bottom panel holds 4× sensor ports (3× 8mm, 1× 6mm) with engraved labels. Right panel holds cutouts for 12V DC, an SD card slot, a rocker switch, and USB programming access.
Console — Custom Electronics Enclosure
This is a comprehensive, dimensionally accurate parametric enclosure designed for DIY electronics. Laid out to securely house a 16×2 character LCD and four tactile push buttons, it uses standard M3 machine screws with captive nut traps for secure and repeatable assembly. The design separates the tactile switch bodies from the actual visible button caps, ensuring a clean and professional appearance. Features Locating Lip: Recessed rabbet ensures the top cover nests tightly and squarely onto the bottom shell. Component-Specific Pockets: 12×12 mm push-button switches are secured from the underside, operated by independent retained caps. Hidden Mounting: The 16×2 LCD is held flush against the top window from the inside via a custom bezel, keeping the surrounding PCB hidden. Directed Ventilation: Cooling slots are restricted to the lower front face, allowing flush wall mounting at the rear. Hardware Needed 4 × M3 × 12 mm machine screws 4 × M3 hex nuts (5.5 mm across flats) 4 × 12×12×7.3 mm tactile switches 1 × 16×2 Character LCD (JHD162A style)
Acoustic Harmonica Silencer Enclosure
A custom-designed acoustic enclosure built to fit a standard 10-hole diatonic harmonica (specifically dimensioned for the Fender Blues Deluxe). This silencer is built to drop external volume during practice while preserving a totally natural playing feel. The enclosure features a wide front opening that allows direct lip contact with the harmonica body, avoiding any forced embouchure changes. The rear of the enclosure acts as a miniature acoustic labyrinth, forcing outgoing air through staggered baffles and multi-chamber pathways to break up sound waves before they exit the exhaust ports. Remixing and Assembly Clearances: The default harmonica cavity includes a 0.4mm clearance, with 4mm of allocated depth at the rear for installing your own acoustic foam. Two-Piece Shell: The model splits into a top and bottom shell, joined by integrated friction-fit alignment pins. Print Settings: Prints completely support-free when the large flat mating surfaces are placed face-down on the build plate. PLA or PETG recommended for rigidity and snap-fit durability.
small Bottle Syringe Clip
A custom-sized double ring designed to couple a 14.5 mm syringe to a 31 mm bottle neck. Syringe bore: 14.5 mm with an 8 mm front insertion slot Bottle bore: 31 mm (snaps on via a 22 mm back slot) Clearance: 4 mm bridge spacing The branding is now recessed 0.6 mm directly into the bottle ring's inner wall, keeping the outer profile completely flush. Check your syringe outer barrel measurement before running this.
Hilti Nuron Battery Mount
A wall-mounted receiver bracket for Hilti Nuron batteries. Heavy battery packs love to lever short brackets right out of the drywall. This bracket gives them a solid vertical footprint to spread that load, catching the battery's sliding interface on an internal U-channel with a dead stop at the base. Internal Channel: 63mm wide (48mm opening) Clearance: Counter-sunk screw holes keep the hardware below the sliding surface Detail: Features a debossed HILTI logo on the backplate that stays clear of the sliding path
28mm — Tapered Syringe Adapter
A specialized dual-ring tool designed to connect a small tapered syringe (5–6 mm) to a 28 mm bottle neck. Features Bottle Bore: 28 mm with a straight 8 mm snap-on cutout, finished with rounded entry tips. Syringe Bore: Tapered from 5 mm at the bottom to 6 mm at the top, ensuring a snug fit. Bridge: A short 6 mm tapered solid bridge connecting the two mounts smoothly. Branding: "SE Tool" engraved directly onto both side flanks of the tapered bridge.
