Walkable SPD-SL Cleat Cover
Created 3 months ago
Description
What it's for
A slip-on protection cover designed for Shimano SPD-SL road cycling cleats. It prevents slipping on hard surfaces like wet cafe tiles while protecting the plastic cleats from premature wear off the bike.
- Features a deep, cross-hatched tread pattern on the sole for traction.
- An internal tapered lip locks the cover securely over the top edge of the cleat hardware.
- A solid rim surrounds the treads to prevent the edges from catching while walking.
Dimensions
- Internal Layout: 75mm long by 55mm wide at the heel, matched to standard SPD-SL profiles.
- Side Walls: 3mm thick for lateral rigidity and protection.
- Base: 4mm thick solid sole, structured to accommodate 2.5mm deep tread grooves.
Materials
Printing this model in a flexible filament like TPU is strongly recommended. The flexibility allows the inner retaining lip to stretch over the cleat body during installation and removal, while the rubber-like material provides the necessary slip resistance.
Remix ideas
- Adapt the internal cavity geometry and overall footprint to fit Look Keo or standard SPD cleat profiles.
- Replace the cross-hatched tread with aggressive horizontal lugs or a custom dot pattern.
- Add a small tether loop to the heel end to leash the covers together when stored in a cycling jersey pocket.
Images
More like this
Explore more in Automotive, RC & Hobby →
Flat Snap-In Interior Trim Cover
