1x6 Toothed Plate

Made by PeterF

Created 3 months ago

Automotive, RC & Hobbylego-compatibletoothed-plate1x6modified-platebuilding-block
Remix this model →

Description

A custom 1x6 building plate combining three 1x2 toothed sections into a single piece.

  • Features a standard 8mm pitch and 3.2mm plate height.
  • Includes 9 teeth arrayed along the front edge.
  • Designed with a hollow underside and clutch cylinders for compatibility.
