80x100mm Dovetail Cleat Drawer Module
Created 3 months ago
Description
A modular 80x100mm drawer shell featuring integrated dual-purpose dovetail tracks. The exterior tracks function as structural rails for rigidly joining multiple units using bowtie pins, and as captive French cleats for drop-in gravity mounts. Includes a matching internal storage tray.
System Specifications
- External Dimensions: 80mm W x 100mm D x 60mm H
- Track Profile: 16mm internal base, 10mm throat
- Clearance: 0.5mm tolerance between drawer and shell
- Assembly: Join units together horizontally or vertically via sliding hourglass pins
- Wall Thickness: 6mm external housing, 2mm internal drawer
