Carteira Rígida para Moedas e Notas

Made by a Guest

Created 1 months ago

Keychains & EDCcarteiraedcmoedasnotasdeslizanteprint-in-place
Remix this model →

Description

Moedas soltas destroem bolsos, e notas amassadas se perdem no fundo da mochila. Carteiras de couro tradicionais não resolvem o problema quando o que você precisa é de estrutura. Esta é uma carteira rígida com tampa deslizante para manter tudo no lugar.

O compartimento principal tem o tamanho exato para cartões de crédito e notas dobradas, enquanto uma divisória dedicada trava as moedas na parte de trás para que não se misturem nem façam barulho.

Detalhes de Impressão e Ajuste

  • Dimensões Internas: Área de cartões/notas com 90x69 mm; área de moedas com 26x69 mm.
  • Mecanismo: Tampa deslizante com trava de fim de curso e ranhuras para o polegar.
  • Tolerância: O trilho deslizante tem uma folga de 0.4mm ao redor da tampa para deslizar suavemente direto da impressora.
  • Impressão: Imprima as duas peças planas na mesa. Não requer suportes.

Photos

Technical views
