Cartoon Giraffe Figure

Created 1 months ago

Decor & Displaymulti-partcartoongiraffetoyfigureanimal
Remix this model →

Description

A modular, multi-part cartoon giraffe figure with exaggerated proportions.

Designed for easy remixing: the body parts are built from basic geometries, meaning you can easily swap the spheres for sharper polyhedrons if you want a low-poly look, or adjust the simple translation coordinates to change the giraffe's neck angle and stance.

Remixing Parameters

  • Leg Height: Currently set to 22mm length with a taper from 9mm to 16mm.
  • Neck Angle: Set to a 25-degree pitch, making it easy to raise or lower the head.
  • Spot Placement: Arranged radially; you can scale or duplicate them to increase coverage.
