Folding Scooter Backrest
Created today
Description
Riding a mobility scooter without back support turns every bump into a spine test. This two-part folding frame bolts directly to a flat seatplate, giving you a sturdy backrest that folds flat out of the way when you need to load the scooter into a car trunk. The heavy-duty hinge locks against a stop block when upright to keep you supported.
Specifications
- Seatplate Mount: 140mm x 100mm overall.
- Mounting Pattern: Four 8.5mm holes spaced 110mm x 70mm apart (fits M8 bolts).
- Backrest Dimensions: 220mm wide by 240mm tall.
- Hardware Required: One M8 bolt and locknut for the main hinge pin.
- Both parts are oriented flat for printing without supports. High infill recommended for the hinge knuckles.
