GridLock — Split Open Drawer Frame
Created 1 months ago
Remixed 2 times
Description
GridLock is a custom-fit drawer divider system completely stripped down to its essentials. Sized specifically to frame out compartments without wasting material on a floor, this open-grid organizer drops directly into a drawer, letting the existing liner or wood bottom show through.
The frame has been split into four cleanly cut sections to allow printing a large 13.5-inch wide organizer on standard 220mm square print plates.
Dimensions
- Total Assembled Footprint: 342.9 mm wide × 228.6 mm deep (13.5" × 9")
- Height: 25.4 mm (1")
- Maximum Piece Size: 171.5 mm × 114.3 mm (fits comfortably on an Ender 3 or Prusa MK series)
Layout
- One full-width front compartment (3.5" deep).
- Two back compartments (one exactly 3.5" wide, the other filling the remaining space).
- No bottom—sits flush on your drawer base.
Assembly Notes
The four quadrants print completely flat without supports. Because the perimeter walls are thin to maximize storage space, they use straight flush cuts rather than bulky joints. Just add a drop of superglue (CA glue) to the seams, press them together on a flat surface, and you're good to go.
Images
More like this
Explore more in Storage & Organization →
Split 13-Inch Slip Box
A simple, cleanly split rectangular enclosure meeting a 3" × 1" × 13" outer footprint. Designed to print standing vertically on the build plate, the two halves meet in the middle with a sliding half-lap joint that handles alignment and friction. Remix Hooks The source relies on a few key parameters that dictate the fit and feel. If you pull this into a remix, check these first: Dimensions: Currently W = 76.2, D = 25.4, and L = 172.6 (for each half, achieving the 330.2mm total length). Tweak these to fit whatever board or gear you are housing. Wall: Set to 3mm. This gives enough meat for the half-lap cut (leaving 1.5mm walls at the joint) without feeling overly bulky. Clearance: The joint runs a comfortable 0.4mm tolerance. Tighten it to 0.2mm if your printer is dialed in and you want a semi-permanent friction fit, or loosen it if it binds. Lip Length: The 15mm overlap keeps the assembled box rigid, but dropping it to 8-10mm would save a bit of plastic if the contents don't flex.
Archiv-Einschub: Schiffe versenken
Ein maßgefertigtes, modulares Schubladen-Regal für Brettspiele und Kartensets (hier ausgelegt auf 150 x 45 mm Boxen). Das Set besteht aus drei Teilen: Regalgehäuse: Eine stapelbare, robuste Außenhülle mit Fase. Schublade: Passgenau mit 0,8 mm Spielraum zum einfachen Herausziehen. Ein Griff an der Front erleichtert das Greifen. Inlay-Buchstaben: Die Schrift ist als 1,5 mm tiefe Aussparung in der Frontplatte angelegt. Die separat gedruckten Buchstaben sind minimal verkleinert (0,15 mm Toleranz) und können nach dem Druck passgenau in die Front eingedrückt werden. Ideal für ein aufgeräumtes Regal, bei dem man jedes Spiel sofort auf der Frontblende erkennt.
Side-Pinned 40-Quarter Dispenser
What it's for A fully mechanical, gravity-fed coin magazine tailored for standard U.S. quarters. It stores a full $10 roll vertically and dispenses exactly $1 (four quarters) per cycle into the palm of the hand. The mechanism relies on a two-stage sliding escapement, now utilizing a side-mounted limit pin to ensure the coin path remains entirely unobstructed during travel. Dimensions Overall Envelope (Dispenser): 34 × 56 × 75 mm (when closed) Slider Thickness: 7.2 mm Coin Bore: 25.2 mm (optimized for 24.26 mm quarters) Assembly The main body, slider, cap, and limit pin print separately without supports. Insert the slider into the main body track, align the side slot with the right-hand hole on the body, and push the limit pin flush into the side countersink to capture the mechanism. Remix ideas Threaded Cap: The top of the magazine tube features a coarse 4mm-pitch thread. Alter the tube height to make a shorter 20-coin version. Coin Bore: Tweak the internal offset diameter for other currencies or custom arcade tokens. Slider Thickness: Scaling the Z-dimension alters how many coins drop per pull (currently dialed for exactly four 1.75 mm thick quarters).
VoltGrid — Print-in-Place Battery Case
A high-capacity, print-in-place storage case holding 104 AA batteries in a skeletal, material-saving grid. Designed specifically for FDM printing without supports. Features Zero Assembly: Prints flat with a fully integrated, captive 45-degree cone hinge mechanism. Just pop it off the bed and fold it closed. Skeletal Organizer: The lower grid provides 0.4 mm of clearance for 14.5 mm diameter AA batteries, but uses open walls to drastically cut filament usage and print time compared to solid block designs. Snap Latch: A flexible cantilever tab locks the lid securely down over a heavy chamfered ledge on the bottom box. Dimensions Flat Printing Footprint: 228 mm × 292 mm Closed Dimensions: 228 mm (W) × 142 mm (D) × 60 mm (H) Capacity: 104 cells (13 × 8 grid)
104-Cell AA Battery Vault
This heavy-duty grid vault keeps 104 AA cells locked down and separated. The front closure uses a single wide flex-arm cantilever built straight into the lid. It swings down to snap automatically over a retaining ledge on the base, holding the lid firmly shut until you pull the finger grip outward. Clearance: 0.4 mm gap on all latch and hinge mechanisms Lid Mechanism: Print-in-place folded hinge Print Layout: Prints fully open and flat on the bed
Monolithic Table Tennis Rack
