Description
A straightforward desk sign or door plaque featuring raised bold text.
Built with separate bodies for the backplate and the lettering, making it a reliable template for custom name plates. It's configured to print flat on the bed; a standard filament swap at 3mm high will snap the text out from the background.
text() module to your own word.cuboid() up to match.Images
A two-up XVIDEOS nameplate set intended as a gift sign for a friend, for desk or shelf display. The model contains two identical horizontal plates, each with a solid black base, a red uppercase “X” at the left, and white “VIDEOS” lettering across the rest of the width. Each plate has a flat back and three underside pockets for 4×2 mm disc magnets. The plates are laid out with a gap and print as two separate pieces. Layout: two identical plates, each 180 × 44.3 mm at about 4.06:1; overall footprint 180 × 99.3 mm with roughly a 10 mm gap; prints as two separate plates. Base: black, 6.5 mm thick, flat back, no supports required. Lettering: single word XVIDEOS, all uppercase; cap height 29.7 mm, about 67% of plate height; text spans about 164 mm with even side margins; heavy geometric sans; letters set tight. Colors: red “X” (#E02A00), white “VIDEOS”, black base; aligned color regions for clean multi-color boundaries. Relief: letters stand about 1.8 mm above the base; raised faces are left square. Magnets: three round pockets per plate, 4.2 mm across × 2.1 mm deep, for 4×2 mm disc magnets; on the long centerline at X = -60, 0 and +60 mm; 120 mm end to end, with the outer pockets 30 mm in from the short ends. Magnet fit: 0.2 mm of play in diameter and depth for a snug fit; about 4.4 mm of base remains above each pocket. Printing: FDM-friendly, flat backside, no supports required.
Goldenrow is a plain, flat diamond panel: a clean blank with a 7.5 in diagonal along X and a 5.5 in diagonal along Y. With no raised artwork, it is a single flat slab that prints quickly with no supports. Dimensions Diagonals: 190.5 mm (7.5 in) along X, 139.7 mm (5.5 in) along Y Thickness: 3 mm Print notes Flat on the bed, no supports needed For speed: 0.6 mm nozzle, 0.3–0.4 mm layers, 2 walls, low infill (10–15%) and a fast top-surface setting Fits a bed of roughly 200 x 150 mm or larger
A flat diamond-shaped panel with diagonals of 7.5 in (190.5 mm) along X and 5.5 in (139.7 mm) along Y, 3 mm thick. A single orchid bloom with a short stem and two leaves is raised on the top face, with the top of the flower pointing toward the +X tip of the panel. Panel: 190.5 x 139.7 mm diamond, 3 mm thick, lightly rounded corners Flower: dorsal sepal, two lateral sepals, two broad petals, lip with side lobes, column, anther cap and throat spots Relief: petals domed with raised center ridges; roughly 10-12 mm above the panel at the highest point Printer: sized for the Flashforge Adventurer 5M (220 x 220 mm bed); supports for the petal undersides can be added in slicer Print time depends on slicer settings; use high-speed profile, low infill and a 0.4 mm or larger nozzle to approach 30 minutes
What it's for Zwei flache Buchstaben-L als Paar: ein normales L und eine spiegelverkehrte Version. Geeignet für Schablonen, Beschriftungen, Dekoration oder Modellbau. Dimensions Je Buchstabe: 40 mm breit, 102 mm hoch, 1,1 mm dick Strichbreite überall 9 mm Abstand zwischen beiden Buchstaben: 10 mm (gesamt 90 mm breit) Remix ideas Abgerundete Ecken oder Fasen an den Kanten Bohrungen zum Aufhängen oder Verschrauben Dickere Ausführung für mehr Steifigkeit
Toiture creuse de 192 × 103 mm pour une maison de 192 × 101,19 mm, hauteur 40 mm, avec pignons fermés percés chacun d'une fenêtre à 4 carreaux alignés. À vérifier avant impression Largeur de la maison : 101,19 mm (le toit déborde d'environ 0,9 mm de chaque côté). Longueur : 192 mm, pignons affleurant les murs. Caractéristiques Coque de 2,5 mm, dessous ouvert. Motif de briques sur les deux pentes. Demi-gouttières Ø3 mm ouvertes vers le haut. Fenêtres : 4 carreaux de 6 × 8 mm, montants de 2 mm. Incompatibilités Aucun ergot ni emboîtement : le toit se colle ou se maintient sur les murs.
Toit à deux pentes creux, ouvert en dessous, dont le bas des pentes se termine au milieu de gouttières arrondies en U, de sorte que seule la moitié extérieure du canal reste visible. Joints d'ardoise gravés sur les deux pentes. Pistes de remix Hauteur du toit : 40 mm au faîtage, donc des pentes d'environ 36°. Réduire cette valeur donne un toit plus plat. Gouttière : profil de 5 × 4 mm, canal rond de 3,4 mm. Élargir le canal pour un meilleur écoulement. Position de fin de pente : le bas des pentes s'arrête à 54,5 mm de l'axe, au centre du canal. Décaler cette valeur change la part de gouttière visible. Compatible avec un garage de 192 mm de large à quatre portes de 40 mm.
