Kawasaki z1100 bar end mirror handle bar adaptors
Created today
Description
A threaded adapter that steps an M18x1 fine-pitch external thread down to an M6x1 internal thread, made for fitting bar end mirrors to the handlebars of a Kawasaki Z1100. The stud is 16 mm tall with no flange, and a 10 mm hex socket in the base lets it be driven in with an Allen key.
Remix hooks
- Hex socket size and depth: 10 mm across flats, 5 mm deep. A deeper socket (7 mm was the earlier value) grips a key better but leaves less solid material around the M6 thread. Change the across-flats value to match a different key.
- Overall height: 16 mm. Taller gives the mirror stem more thread to bite into; shorter reduces how far it protrudes from the bar end.
- Thread fit: both threads are modelled at nominal size. FDM usually needs 0.1–0.2 mm of adjustment on the M18x1 outside and the M6x1 inside, so print a short test ring first.
- Add a stop: there is no flange, so insertion depth is set by feel. A thin collar or a shoulder on the mating part would give a hard stop.
- Pairs with: a lock nut or thread-locking compound on the M6 side to keep a mirror from backing out under vibration.
Starting dimensions
- External thread: M18, 1 mm pitch
- Internal thread: M6, 1 mm pitch, through the full height
- Height: 16 mm
- Socket: 10 mm hex, 5 mm deep
Check the thread on your actual bar ends before relying on it. Print in a tough material such as PETG or ABS, since the part sees vibration and weather.
Images
More like this
Explore more in Automotive, RC & Hobby →
Seatbelt Buckle Holder with Snap Clips
A twin seatbelt buckle holder with two separate snap clips. Each clip bridges the top of a pocket and clicks into grooves on the sleeve, so the buckle can't tip out. Remix hooks Bar width (8 mm): widen it for a firmer hold, or narrow it for easier buckle removal. Groove height (18 mm up the sleeve): move it to change how far the clip sits above the pocket. Barb depth (about 1 mm): increase it for a stronger snap, or reduce it if the arms feel stiff in your filament. Arm thickness (2.2 mm): thinner flexes more, thicker holds more. Pairs with: the original 33 x 53 mm pockets, 28 mm sleeves, and 130 x 64 mm footprint, all unchanged. Print the clips flat as laid out, with the bar on the bed. PETG flexes better than PLA for the arms.
25mm Tactical Tabletop Tokens
A complete set of nine 25mm wargaming tokens tailored for tabletop tracking. Designed with a clear separation between the base and the raised lettering, making them perfectly suited for a mid-print filament swap or a multi-material system. Specifications Dimensions: 25 mm diameter, 4 mm overall height. Tolerances: The raised text and outer rim sit exactly 1 mm above the base layer, creating a clean Z-height transition for color changes. Printability: No supports required. The bottom edges feature a 1 mm chamfer to prevent elephant-foot distortion on the first layer, ensuring the tokens remain perfectly circular and easy to pick up from flat tables. Layout: Arranged in a flat 3x3 grid for immediate batch printing. Can be split into individual models in the slicer if needed.
Double Seatbelt Buckle Holder, Backseat
Two seatbelt buckles flop around and fall into the seat gap, so this holder stands both upright side by side in the backseat of a Toyota Sienta. Each 33 x 53 mm pocket goes straight through the base, so the buckle and webbing pass through with nothing blocking the bottom. Pocket size: 33 x 53 mm each, sized for a 31 x 51 mm buckle Sleeve height: 28 mm above a 6 mm base Overall footprint: 130 x 64 mm Centre screw hole: 4.5 mm Print flat on the base, no supports needed
Dollhouse Slide Flume
