Large Cable Organizer Box
Created 1 months ago
Description
A high-capacity cable management box with a fitted drop-in lid, sized to house bulky power strips, large transformers, and excess cable coils. The rear panel features two mouse-hole style arch cutouts seated flush with the interior floor for easy drop-in cable routing without requiring cables to be threaded through tight slots.
What it's for
- Concealing power strips, power bricks, and cable runs on desktops or floors
- Floor-level cable pass-through that keeps cords flat against the surface
- Dust protection with an easy-access lift-off lid
Dimensions
- Internal Clearance: 215.9 mm (8.5") W × 292.1 mm (11.5") D × 127.0 mm (5.0") H
- Wall Thickness: 3.0 mm
- Port Size: 40 mm wide × 64 mm high arched openings flush to the floor plate
- Outer Footprint: 221.9 mm × 298.1 mm × 133.0 mm (excluding lid hover offset)
Print notes
- Print the box base-down with no supports needed for the arched ports.
- The lid prints flat on its top face for maximum surface quality and bed adhesion.
- Requires a build volume of at least 300 mm × 225 mm.
