Modular Cat Puzzle Scratcher
Created today
Description
A modular puzzle and scratcher assembly designed to keep a cat engaged while filing their nails. The unit bolts together in layers, enclosing a labyrinth meant to hold treats or toys.
The stack consists of four distinct pieces:
- Base Plate: Features a recessed pocket to accurately seat the scratch tray.
- Filing Tray: A removable insert that sits at the bottom of the maze, complete with a finger hole for easy swaps.
- Maze Walls: A 20mm deep labyrinth structure with reinforced corner bosses for clamping force.
- Top Plate: Incorporates multiple circular and elongated paw cutouts to allow access to the maze below, plus a dedicated raised ribbed section for exterior nail filing.
Designed to be clamped together using four M4 bolts passing through all outer corners. Note that the provided file lays out the parts in an exploded view to clearly show the internal structures.
