Made by MintHacksaw
Created 1 months ago
Description
A vintage-style brand badge featuring raised script typography and an under-swoosh, framed by a continuous outer rim. Designed to resemble classic cruiser motorcycle tank badges and dealership signage.
Features:
Images
BeamWedge is a shallow mounting wedge for a motorcycle number-plate lamp. It tilts the lamp down toward the plate instead of into the eyes of people behind, while the 53 mm × 13 mm face matches the lamp body and keeps the profile compact. A pair of screw holes and a bevelled central cable opening let the lamp sit cleanly on a number-plate holder, and the 5.5 mm body thickness with a 3 mm thin edge keeps the wedge unobtrusive. All four corners are rounded at 3 mm radius, so no sharp points sit against the holder or the lamp body. The set also includes two 11 mm angled washers as separate parts. They sit on the back side under the screws to correct the mounting angle, with a low-profile wedge section, 4 mm centre holes, and a slope that matches the back of the wedge. Fit each washer with its thick edge on the side where the wedge is thinnest. Fit and features Slightly shallower than 15° downward tilt for aiming the lamp at the plate 53 mm wide and 13 mm tall to match the lamp body Two 5.5 mm screw holes at 39 mm centres 10 mm central cable hole with a 0.75 mm bevel on the flat back face, flaring to about 11.5 mm at the surface 5.5 mm body thickness with a 3 mm thin edge 3 mm rounded corners on all four points Two separate 11 mm angled washers with 4 mm holes, about 2.35 mm thick at the thick edge and 0.25 mm at the thin edge Print notes The wedge prints lying on its large flat back face, with the cable-hole bevel against the bed and the sloped face pointing up, so it needs no supports. The bevel leaves roughly 0.7 mm of material above and below the cable opening across the wedge's 13 mm height. That is thin but printable — run extra perimeters so the narrow bands around the hole hold up. The angled washers print flat, one face down, as separate parts, with no supports needed. Their 0.25 mm thin edge is fragile; if it prints poorly, raise it to about 0.4 mm. Before printing Check the 39 mm screw spacing and the 10 mm cable opening against the lamp before printing. The washer holes are 4 mm, which suits M4 fixings; they are tight for the wedge's 5.5 mm fixing holes, so confirm the screw size before printing.
A two-piece hinged clamp for a 38.5 mm motorcycle fork tube, with an L-shaped bracket that carries a 10 mm hole and a 4 mm wire slit for a turn signal post. The halves swing open on an M3 hinge pin and close with one M6 bolt and a hex nut pocket, so the fork stays on the bike. The hinge sits outside the ring on small webs, so the knuckles clear the opposite half when it swings. Bore: 38.0 mm Height: 24 mm, wall 3.5 mm Hinge pin: M3 × 30 bolt or 3 mm rod Clamp bolt: M6 with nut Print the front half with its L bracket, and the rear half separately
A 2x4 plate with no way to pass a Technic pin or axle through it is a dead end in a studless build. This plate has three holes on the centre line, so pins and axles go straight through. Six are laid out flat for one print run. Key numbers Plate: 32 x 16 mm, 3.2 mm thick, studs on 8 mm pitch Studs: 4.8 mm diameter, 1.8 mm tall Holes: three, 4.8 mm diameter, on the centre line, 8 mm apart Print: flat, no supports, 0.2 mm layers; test one first to check clutch fit
Gancho de garrafa de treino em J, 200 mm, com braçadeira bipartida na base: corpo fixo ligado à haste e tampa separada que fecha por encaixe de pressão ao redor da alça de 12 × 24 mm. Pontos de remix Snap-fit: ganchos flexíveis de 8 mm de comprimento, 1,8 mm de espessura e ressalto de 0,6 mm (armlen, armt, ridge). Entrada em rampa, retenção reta. Folga: 0,2 mm entre tampa e corpo (gap). Trava extra: furo M3 em gota atravessando tampa e corpo, com porca sextavada embutida no lado +X. Paredes: wallx (6,4 mm) e wallf (7,5 mm) definem o tamanho externo; reduza se o furo M3 for dispensado. Haste e gancho: inalterados, seção 10 × 14 mm, bojo de 40 mm, boca de 34 mm. Combina com: parafuso M3 e porca M3 (opcionais); imprima corpo e tampa separados em PETG ou PLA.
A single-arm servo horn for the SG90 micro servo, with a 3.2 mm linkage hole 12 mm from the output shaft centre. Fitment Fits: SG90 and compatible 9 g servos with the 21-tooth, ~4.8 mm output spline. Does not fit: MG90S metal-gear servos with a different spline count, or 25T servos such as MG995/MG996. Arm: 12 mm centre distance, 4 mm thick, rounded edges. Check before printing Test the spline bore on a scrap print. Bore size is ~4.9 mm with small tooth notches, and printer tolerance varies. Adjust it if the fit is loose or tight. The part prints flat with no supports, and PLA works.
Straight and curved RC track pieces sized to fit a 250 x 250 mm print bed, using the same 90 mm wide track and bulb-and-socket latch as the rest of the set. What it fits Built for printers with a 250 x 250 mm bed or larger. Mates with the existing 90 mm wide pieces (80 mm clear lane, 5 mm rails) through the same latch with 1 mm clearance. Pieces Straights: 50 mm and 150 mm (the 200 mm straight also fits). 180° hairpin at 70 mm centreline radius, about 230 mm wide. 30° at 250 mm radius, 45° at 200 mm, 60° at 150 mm, 90° at 120 mm. Check before printing The footprint of each piece is measured from the model, but measure your bed's usable area, since brims and clips reduce it. Does not fit The earlier 180° hairpin at 100 mm radius, the main junction (about 440 mm) and the multi-way junctions are larger than a 250 mm bed. The latches have not been test-fitted.
