Packout M18 Router Insert
Created today
Description
What it's for
A custom drop-in tray engineered to convert a half-section of a Standard Milwaukee Packout Organizer into a dedicated M18 router station. It features a contoured cradle for the router body with its battery attached, a wide pocket for the base plate, a large accessory bay for the edge guide and wrench, and a 12-slot storage grid for 1/4-inch shank router bits. Scalloped finger pulls make it easy to lift the router out.
Dimensions
- Footprint: 280 mm × 200 mm
- Height: 60 mm
- Bit Storage: 12 holes, 7.2 mm diameter (for easy clearance of standard 1/4" shanks)
Print notes
Given the large 280 mm length, this will require a reasonably large print bed. A robust infill (15–20% gyroid) is recommended to support the weight of the tool. The design rests entirely flat on the build plate and requires no supports.
