PRINTYTRON 1 LAMP

Created 1 months ago

Decor & Displaye27-lamptwisted-shadegeometriccustom-logodesk-lampfuturistic
Remix this model →

Description

A striking, futuristic luminaire that plays with light and geometry. The lamp features a brutalist hexagonal base grounding the piece, while a twisting, twelve-sided spatial shade tapers upward into the atmosphere. The heavy base carries the LUMA DESIGN marque on its forward facet, giving it the presence of a bespoke studio piece.

Assembly Notes

  • Socket Fit: Designed for a standard E27 threaded lamp socket. The socket drops through the 42mm central bore.
  • Stacking: The twisting shade rests directly on the base; secure both layers together using the threaded retaining ring included with your E27 hardware.
  • Wiring: Features a generously hollowed underside and a rear-facing cable channel to keep the footprint flush against the desk.
  • Printing: The base and shade are separate parts. The shade's gentle taper and 3mm base floor make it suitable for standard shell printing.

Images

SUPPORT PRINTYTRON
Tip Jar
Printytron built this for free. If it saved you a trip to the shop, a tip helps keep it free.
Need filament at a great price?
Printing this one? Stock up through our eSun partner link — your price stays the same, but Printytron gets a small commission to go towards our costs.
Miniature Suitcase with Handle, Wheels and Weight Display

Miniature Suitcase with Handle, Wheels and Weight Display

What it's for A miniature suitcase standing upright on four sideways-mounted wheels, with a pull handle on top and a small thin scale plate set into the top face just in front of the handle. The plate carries a raised readout of 52 lbs, so the piece reads as a luggage scale at a glance. It works as a small desk ornament, a travel-themed display piece, or a scale prop for a dollhouse or diorama. The whole thing is one plain neutral finish, with no colour coding or recessed front screen. Dimensions Overall footprint: 60 × 24 × 100 mm (width × depth × height, as it sits on the print plate) Wheels: mounted sideways, axles running across the width of the case, so the body rests on them Weight plate: a small thin panel on the top face, in front of the handle Readout: raised 52 lbs lettering, picked as a believable airline-limit weight — say if you want a different figure Print notes The model prints as a single piece lying on its wheels, so no supports are needed under the body. The raised readout is small — a 0.4 mm nozzle with fine layer heights keeps the digits and the "lbs" legible, and a 0.25 mm nozzle gives crisper text. The thin top plate is shallow, so check that your bridging over that area is clean. Remix ideas Change the readout to a different weight, or leave the plate blank for a custom label. Swap the handle for a telescoping version, or add corner guards to the body. Scale the case up to hold small items, or down to keyring size. Finish A single neutral colour suits the plain, serious look — the design relies on shape and the raised text rather than colour contrast, so any filament works.

3 days agoRemix →
Modular Orrery Kit, 100 mm, 12 Parts

Modular Orrery Kit, 100 mm, 12 Parts

A 12-piece kit for a 100 mm gimbal-ring orrery, laid out as separate parts. Each part lies flat on the build plate, so no support is planned for any of them. The parts are not joined to each other. The frame is split into two halves joined by offset tabs and M3 screws. The three silver rings pivot on integral pins that seat in blind sockets in the neighbouring part. The hub carries three blue arcs and a blue gear held by a cap. Parts Frame halves (2): dark, 100 mm outer diameter, 12 mm deep, 84 mm bore. Each has a pivot socket and tab-and-pocket joints. Gear ring (1): 48 positions with the two pivot positions left empty, 83.6 mm outer diameter, 8 mm deep. It is decorative and meshes with nothing. Silver rings (3): 73 mm, 61 mm and 49 mm outer diameter, 6 mm thick. They are nested and joined by 3.6 mm pins in 4.0 mm sockets. Hub (1) and cap (1): 20 mm hub with a 4 mm boss. Blue arcs (3): 130° arcs at different radii. Each swings on its own 3 mm pin. Blue gear (1): 12 teeth, 4.4 mm bore, held on the hub boss by the cap. Assembly order Seat the gear ring in one frame half. Insert the outer ring pins through the gear ring into the frame sockets. Close the second half and fasten the two joints with M3 screws, with the 2.6 mm pilot holes in the tabs as the thread. Press the inner rings together from outside in, then fit the hub, arcs, gear and cap. Notes Print time is not estimated and the 120-minute limit is not verified. Clearances and movement are untested. Arc swing is not limited, so an arc can hit the ring pins. The blue gear has no mating gear.

3 hours agoRemix →
