RC Car Bevel Gear Rear Drive
Created today
Description
A rear-axle drive for an RC car where the motor shaft has to turn 90° into a cross-car axle without the gears skipping or the motor shifting. This set uses a 12-tooth pinion and 24-tooth crown gear (2:1) on a 103.9 mm × 6 mm axle, with an open motor cradle instead of a closed box.
Key numbers
- Gears: module 1.5, 20° pressure angle, 4 mm face width, 90° shaft angle
- Pitch cone angles: 26.57° (pinion) and 63.43° (crown); cone distance about 20.1 mm
- Pinion bore 2.1 mm, crown bore 6.2 mm, both with M3 set-screw holes in the hubs
- Axle supports: 6.4 mm through-hole plus a 17.3 mm seat for 606 bearings (6×17×6)
- Base: 84 × 92 × 5 mm, M3 holes (3.4 mm clearance); cradle slots allow forward and back adjustment
- Motor cradle parameters at the top of the file: mw, mh, wall, saddle_l, saddle_y. Measure the real motor and edit them
- Cover is open at the bottom, with two M3 ears at the rear
Printing
- Print gears with the hub facing up or down on the bed; PETG or nylon preferred
- Cover prints open-side up without supports
- Axle is a separate 6 mm steel rod; M3 screws hold supports, cradle, straps and cover
Images
More like this
Explore more in Automotive, RC & Hobby →
Duo Gear — 30T and 15T Spur Pair
Duo is a matched pair of spur gears at a 2:1 ratio: a 30-tooth gear measuring 90 mm across the tips and a 15-tooth partner, both 10 mm thick. Tooth size is shared, so they mesh directly and are laid out at the correct centre distance. Features 30-tooth gear: 90 mm outer diameter, 10 mm bore 15-tooth gear: same tooth pitch, 8 mm bore Both 10 mm high, flat on the bed Pre-positioned in mesh Print notes Print flat, no supports. Adjust bores to fit your shafts.
Double Seatbelt Buckle Holder, Backseat
Two seatbelt buckles flop around and fall into the seat gap, so this holder stands both upright side by side in the backseat of a Toyota Sienta. Each 33 x 53 mm pocket goes straight through the base, so the buckle and webbing pass through with nothing blocking the bottom. Pocket size: 33 x 53 mm each, sized for a 31 x 51 mm buckle Sleeve height: 28 mm above a 6 mm base Overall footprint: 130 x 64 mm Centre screw hole: 4.5 mm Print flat on the base, no supports needed
Retro TV Enclosure for No-Solder RP2040 Builds
A two-piece retro TV shell designed to house a no-solder RP2040 video player. The clamshell locks together with a built-in snap fit, offering exactly 150×80×50mm of internal space. Both halves print flat on the bed without supports. Front Bezel: Features a sloped CRT-style screen cutout with an internal ledge for a 2.8" display, twin 7mm dial holes, and integrated speaker vents. Back Shell: Includes a bottom-edge USB-C cutout and classic rear cooling vents. Snap Fit: A 4mm friction lip with interlocking bumps holds the enclosure securely together.
Space Command Console Toy
The keyboard belongs to you. The TV remote belongs to you. The oven dials are strictly off limits. But they still want to press buttons, and everything they reach for has a consequence. This console solves that. It’s a chunky, slanted control panel built to take a hammering. The throttle is a captive slider that prints fully in place—no assembly, just crack it loose and it glides. The giant red and green buttons sit on thin printed hinges, giving them enough flex to feel like a real press without needing actual springs or hardware. The dials and radar screen are solid topographic features that add tactile feedback without weak points. Printing Notes Dimensions: The base fits squarely on a 180x130mm footprint. Print-in-Place Clearance: The slider runs in an internal T-slot with a generous 0.5mm clearance on all sides, making it easy to free up on almost any FDM machine. Orientation: Designed to sit entirely flat on the build plate. The 13-degree slope of the panel is built into the geometry, so the internal bridges and tracks print parallel to the bed. Settings: Standard 0.2mm layer heights work beautifully. Three perimeters recommended to keep the compliant button hinges tough.
Seatbelt Buckle Holder with Snap Clips
A twin seatbelt buckle holder with two separate snap clips. Each clip bridges the top of a pocket and clicks into grooves on the sleeve, so the buckle can't tip out. Remix hooks Bar width (8 mm): widen it for a firmer hold, or narrow it for easier buckle removal. Groove height (18 mm up the sleeve): move it to change how far the clip sits above the pocket. Barb depth (about 1 mm): increase it for a stronger snap, or reduce it if the arms feel stiff in your filament. Arm thickness (2.2 mm): thinner flexes more, thicker holds more. Pairs with: the original 33 x 53 mm pockets, 28 mm sleeves, and 130 x 64 mm footprint, all unchanged. Print the clips flat as laid out, with the bar on the bed. PETG flexes better than PLA for the arms.
Published
A dashboard phone cradle perfectly sized for an iPhone 15 Plus in a standard case, built with a heavy-duty vent mount clip. Center Star Motif: A single crisp five-point star punched through the bottom face. Vent Clip: Uses cross slits for a snug friction fit on standard car air vent louvers. Side Access: The midsection is cut away, leaving only top and bottom cuffs so your side buttons remain entirely clear.
