Reach — Telescoping Baton
Created today
Description
A compact, print-in-place telescoping baton that expands from a pocketable 8-inch handle into a full 23-inch extension with a flick of the wrist. The segments are designed to print fully assembled with precisely calibrated clearances, locking into place securely upon extension.
Dimensions
- Collapsed Length: 200 mm (approx 8 inches)
- Extended Length: ~580 mm (approx 23 inches)
- Handle Diameter: 40.6 mm (1.6 inches)
Print Notes
- Print the main assembly vertically in its default orientation.
- Do not use supports inside the segments.
- The included base cap friction-fits into the bottom once printed to retain the segments.
Images
More like this
Explore more in Keychains & EDC →
Micro Print-in-Place Joystick
This is a print-in-place ball joint that acts as a miniature thumb joystick. The entire assembly prints as one welded-together block with an internal 0.4 mm gap; once it's off the build plate, a firm snap frees the stick to rotate and swivel in the base. It is designed to be as small as FDM printers can reliably manage without snapping the stalk.
Visitor Pass Base Frame
A solid, minimal frame designed to house a standard 3D-printed visitor pass insert. The base acts as a rigid backing plate, featuring a recessed cavity with a slight continuous inner overhang. This tapered lip allows a flat insert to snap securely into place while printing entirely without supports. Overall Dimensions: 120 mm × 75 mm. Thickness: 2 mm solid floor with a 1.8 mm raised border (3.8 mm total height). Recess Size: 110 mm × 65 mm, providing roughly 0.2 mm clearance around a 109.6 mm × 64.6 mm insert. Retention: 0.2 mm continuous 45-degree internal chamfer at the top edge to lock the insert in place. Printability: Prints perfectly flat on the bed; no supports required.
60mm Keyring Carabiner Clip
A 60x30mm print-in-place compliant carabiner designed to interface with standard split-ring keychains and lightweight everyday carry items. The frame features a 5mm constant cross-section with alternating triangular truss cuts along the spine to reduce material weight without compromising the hinge action. Fitment and Tolerances Clearance: The interlocking latch mechanism relies on a 0.4mm printed gap. Ensure flow rate and horizontal expansion are calibrated to prevent the gate from fusing to the catch. Hardware: Accepts standard flat or wire keyrings up to 4mm in thickness through the inner loop. Incompatibilities: This is a decorative thermoplastic clip for keys and pocket tools. It is strictly non-load-bearing. Do not use for climbing, rigging, securing heavy equipment, or any life-safety applications.
Support-Free Braided Crucifix Pendant
Pendants that look good from the front usually refuse to sit flat on a print bed, leaving you picking stringy supports out of fine details for half an hour. This cross solves that by keeping a meticulously carved face and an intertwined braided rope lashing, while silently shaving the entire rear face perfectly flush. It drops right onto the build plate and prints in one clean shot. Dimensions: 34 mm wide, 55 mm tall Mounting: Heavy-duty 3.5 mm integrated through-bore, practically un-snappable Printability: Zero supports needed. The back is sliced flat so it anchors perfectly to the bed.
FlexiLink — Llavero Articulado TAMARA
Este es un llavero articulado de impresión print-in-place que no requiere soportes ni montaje. Las letras conforman el cuerpo de los propios eslabones, y se unen mediante un sistema de pasador cautivo oculto con holguras diseñadas para liberar el movimiento tan pronto como la pieza termina de imprimirse. Características Legibilidad mejorada: Los pasadores se conectan directamente a los laterales de las letras, manteniendo el interior limpio. Articulaciones sueltas: Diseñadas con 0.4 mm de tolerancia, pensadas para la calibración habitual de PLA en impresoras modernas. Sin ensamblaje: Todo el llavero se imprime como un solo cuerpo que se pliega. Anilla integrada: El extremo cuenta con una gaza con espacio para una anilla estándar de llaves.
Chubby Sitting Hamster Keychain
A compact, sitting hamster figure modelled with exaggerated, rounded proportions for a chunky silhouette. The base is sheared flat to allow support-free printing directly on the build plate, and a reinforced loop is integrated into the upper back of the head. Dimensions: ~28mm wide, 30mm tall. Keyring Loop: 3.2mm horizontal bore, heavily chamfered outer ring. Print Settings: Print upright. The limbs and facial features intersect closely with the main body to minimise overhangs; no supports are required.
