Serpentine Visor Glasses Clip
Created 16 days ago
Description
A continuous serpentine sweep of tensioned plastic, this dual-sided clip mounts securely to a vehicle's sun visor while gripping a pair of sunglasses on the opposing side. The unbroken S-curve silhouette allows both arms to act as heavy-duty leaf springs, utilizing the material's natural memory to maintain a firm hold without the need for metal hardware.
Fitment & Geometry
- Visor Mount: Sprung to accommodate standard 8mm to 12mm car visors, expanding up to 14mm with an inward-facing tongue to lock onto the edge.
- Optical Jaw: Features an internal wedge taper that slopes from 6mm down to 2mm, firmly trapping thick acetate frames or thin wire rims.
- Structural Flow: Designed to be printed flat on its side, ensuring the layer lines run parallel to the spring arms to prevent delamination under continuous stress.
Photos
Technical views
