Slotted Junk Drawer Dividers
Created 1 months ago
Description
A set of four interlocking drawer dividers designed for junk drawer triage. The slotted design allows the pieces to be crossed at right angles to create custom-sized grid compartments.
What it's for
- Organizing 35 cm deep drawers.
- Creating modular grids for loose items, hardware, or office supplies.
- Taming messy spaces with a rigid interlocking structure.
Dimensions
- Length: 350 mm per divider.
- Height: 50 mm.
- Thickness: 2.4 mm walls.
- Slot spacing: Spaced every 50 mm along the length, with flared entries for easier assembly.
Remix ideas
- Modify the slot spacing to create custom, unequal compartment sizes.
- Adjust the overall length to fit shallower or deeper desk drawers.
- Increase the height for deeper toolboxes or storage bins.
