Spring-Loaded Telescoping TP Spindle
Created today
Description
A two-piece telescoping spindle designed to replace a broken toilet paper roll holder, ending a three-week reliance on a makeshift chopstick. The outer tube features a scalloped grip ring to assist in compressing the internal spring, while the inner piston uses a flex-slotted retention bump to snap into place and prevent the rod from flying apart when removed from the wall.
Specifications
- Mechanism: Telescoping slide providing approximately 30mm of internal travel.
- Retention: Snap-fit lip on the outer tube mates with flex-slots on the inner piston.
- Grip: Scalloped 28mm outer ring for leverage against spring tension.
- Hardware Required: Accepts a standard metal spring within the 10mm central cavity.
- Mounting: Tapered 6mm end pegs fit standard bathroom wall fixtures.
Photos
Technical views
