Stealth Pillion Cowl Cap

Made by a Guest

Created 3 months ago

Automotive, RC & Hobbymotorcyclefairingpillion-cowlstealthlow-profilestrap-mount
Remix this model →

Description

A sharp, faceted pillion cover that borrows heavily from the brutalist angles of modern stealth fighters. Designed to sit directly over a standard passenger seat rather than replacing it, this cap runs extremely low-profile to keep the tail looking clean when riding solo.

Fastening

  • Internal Anchors: Four distinct strap loops are tucked into the side margins of the hollow cavity.
  • Routing: Run flat webbing (up to 25mm wide) side-to-side through the loops and directly underneath the seat pan.
  • Fitment: Wide, generic clearances mean it acts as a floating cap, letting the straps pull it snug without needing latch-specific hardware.
