Suporte Bíblia com Amplificador Passivo
Created today
Description
Suporte de mesa para smartphone projetado no formato de uma Bíblia fechada clássica, completo com textura simulada de páginas, lombada nervurada e cruz em relevo na capa.
Além de manter o dispositivo em um ângulo confortável de leitura, o suporte funciona como um amplificador de áudio acústico passivo. A base do berço do celular possui uma abertura que se conecta a uma câmara oca interna; o som emitido pelo alto-falante inferior é captado e afunilado para a abertura frontal projetada entre as "páginas".
- Compatível com a maioria dos smartphones (berço com 85 mm de largura e 16 mm de profundidade).
- Ângulo de visualização em 18 graus.
- Amplificador 100% passivo: sem baterias ou eletrônica.
- Câmara interna otimizada para ser impressa em FDM sem necessidade de suportes internos (o teto do canal guia o plástico de forma segura).
- Dimensões globais: 160 × 130 × 42 mm.
Photos
Technical views
