Ühe Otsaga Suletud Sahtlikarp

Made by DeftLlama

Created 1 months ago

Storage & Organizationsahtelkarpstorageorganizerno-supportsprint-in-placeslip-fit
Remix this model →

Description

Sahtel kiilub kinni, sest pole kuskilt korralikult kinni võtta. See on suletud tagaseinaga lihtne kest, millel on nüüd sahtli ees korralik väike näpu-kõrgendus, et seda saaks mugavalt ja ilma küüsi murdmata välja tõmmata.

  • Mahutavus: Täpselt 200 × 50 × 50 mm kasulikku ruumi.
  • Seinad: 1.5 mm, prinditav ilma tugedeta.
  • Liikumisruum: 0.5 mm lõtk külgedel tagab sujuva liugumise.
