Description
Large vehicle prints warp, lift off the bed, or take days to finish. Splitting the chassis into smaller, hollowed quadrants stops the curling and lets the pieces finish quickly. This is the left-side foundation.
Images
A 1/10-scale ladder-frame chassis for a rear-wheel-drive RC hot rod truck. The frame is 340 mm long with 95 mm rail spacing and a 260 mm wheelbase, and it includes a front servo plate, motor plate, battery tray with cutouts, rear diff block, six body-mount posts, and placeholder axles and wheels. The dimensions are a starting point rather than a scale copy of a full-size Factory Five 1935 truck, and the mounts and axles are not sized to a specific motor, diff, servo, battery or drivetrain. Check hardware fit before printing. The frame length exceeds many printer beds, so plan for a large-format printer or split the frame into sections. Frame: 340 mm long, 95 mm rail spacing, 260 mm wheelbase Includes: five crossmembers, front servo plate, motor plate, battery tray with cutouts, rear diff block, six body-mount posts Placeholder parts: axles and wheels, not matched to a specific drivetrain Printing note: 340 mm frame length may require a large bed or sectional printing
A single-arm servo horn for the SG90 micro servo, with a 3.2 mm linkage hole 12 mm from the output shaft centre. Fitment Fits: SG90 and compatible 9 g servos with the 21-tooth, ~4.8 mm output spline. Does not fit: MG90S metal-gear servos with a different spline count, or 25T servos such as MG995/MG996. Arm: 12 mm centre distance, 4 mm thick, rounded edges. Check before printing Test the spline bore on a scrap print. Bore size is ~4.9 mm with small tooth notches, and printer tolerance varies. Adjust it if the fit is loose or tight. The part prints flat with no supports, and PLA works.
Straight and curved RC track pieces sized to fit a 250 x 250 mm print bed, using the same 90 mm wide track and bulb-and-socket latch as the rest of the set. What it fits Built for printers with a 250 x 250 mm bed or larger. Mates with the existing 90 mm wide pieces (80 mm clear lane, 5 mm rails) through the same latch with 1 mm clearance. Pieces Straights: 50 mm and 150 mm (the 200 mm straight also fits). 180° hairpin at 70 mm centreline radius, about 230 mm wide. 30° at 250 mm radius, 45° at 200 mm, 60° at 150 mm, 90° at 120 mm. Check before printing The footprint of each piece is measured from the model, but measure your bed's usable area, since brims and clips reduce it. Does not fit The earlier 180° hairpin at 100 mm radius, the main junction (about 440 mm) and the multi-way junctions are larger than a 250 mm bed. The latches have not been test-fitted.
What it's for 30×40 mm 底板,前端带两片独立固定耳片,用于锁 SG90 舵机自带的安装耳。 Dimensions 底板 30×40×2 mm,圆角 R1,2 个 φ2 孔,孔距 22 mm 耳片各宽 4.2 mm、厚 2 mm、高 14.5 mm 耳孔 φ2,中心距 28 mm,孔内侧距耳片内边 0.2 mm Remix ideas 加宽耳片内侧以增加强度 恢复 U 型侧壁
ServoLink is a compact single-bar crank arm for SG90 micro servos. One end carries a 21-tooth spline socket that grips the servo output shaft. The other end has a 3.2 mm round hole for a linkage pin or screw. The part is flat and printable without supports. Dimensions Hole centre to centre: 12 mm Thickness: 4 mm Left hole: SG90 spline, about 4.9 mm across the teeth Right hole: 3.2 mm diameter Hub: 9 mm round, arm end: 7 mm round, with softened edges Print notes PLA, printed flat, no supports The spline is sized close to nominal. Scale the hole slightly if your printer runs tight or loose.
A two-piece hinged clamp for a 38.5 mm motorcycle fork tube, with an L-shaped bracket that carries a 10 mm hole and a 4 mm wire slit for a turn signal post. The halves swing open on an M3 hinge pin and close with one M6 bolt and a hex nut pocket, so the fork stays on the bike. The hinge sits outside the ring on small webs, so the knuckles clear the opposite half when it swings. Bore: 38.0 mm Height: 24 mm, wall 3.5 mm Hinge pin: M3 × 30 bolt or 3 mm rod Clamp bolt: M6 with nut Print the front half with its L bracket, and the rear half separately
