150mm Bayonet Twist Vault

A 150mm mechanical drop-in vault, built around a 50mm twist-lift track.

This replaces the friction fit of the original 150mm Borg Friendship Vault with a proper bayonet mechanism. The outer cage runs three 18mm tall helical tracks to guide the core. The top cap terminates in a 40mm hexagonal drive plug; dropping it onto the core and twisting counter-clockwise forces the payload to lift 50mm out of the chassis.

• Bore Clearance: The 98mm core runs inside a 102mm cage bore. Verify your machine holds tolerances on large cylinders.
• Support-Free: The massive 90mm flat bridges of the original have been replaced by mechanical vertical slots with 45-degree angled roofs. No supports needed for the cage or core lugs.
• Payload Capacity: The hollow inner void measures 76mm in diameter by 110mm deep.

To assemble, line up the core lugs with the vertical entry slots on the inner walls of the cage, push down to the top stop, and twist right to lock it securely to the bottom.
