240mm Kidney Pool With Slide Receiver
Created 1 months ago
Description
A 1:6 scale kidney-shaped pool basin optimized for flat build plates, featuring an integrated U-channel slide receiver on the front edge.
The structure prints as a single monolithic part with no overhangs requiring support material. The basin wall is swept to provide a soft 3mm top bevel, and the interior floor transitions via a 4mm chamfer to prevent sharp 90-degree corners that trap water or dirt.
Dimensional Specs
- Max Footprint: 240 mm × 175 mm (fits standard 256 mm build volumes).
- Basin Height: 50 mm overall; 44 mm usable interior depth.
- Wall Thickness: 10 mm continuous structural wall.
- Slide Interface: 70 mm wide channel with 15 mm vertical retention walls and exactly 15 mm of socket depth to positive stop.
- Base Plate: Solid 6 mm thick floor, printing entirely flat to the bed.
